Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics

1pcs
MOQ
$0.50 - $10.00/pieces
가격
Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
유형: Quartz 플레이트를 제거하십시오
애플리케이션: 반도체, 광학
두께: 0.5-100mm
모양: 혼합
처리 서비스: 굽힘, 용접, 펀칭, 연마
제품 이름: 석영 판
재료: SIO2> 99.99%
밀도: 2.2g/cm3
작동하는 온도: 1150 ℃
경도: 모스 6.5
멜트 포인트: 1750-1850 50
산성 내성: 세라믹보다 30 배, 스테인레스 스틸보다 150 배
크기: 사용자 정의
어닐링 포인트: 1180 ℃
스트레인 포인트: 1100 ℃
포트: 상하이와 Qindao 항구
강조하다:

High Temperature Resistance Quartz Glass Plate

,

High Light Transmittance Fused Silica Plate

,

High Hardness Optical Quartz Plate

기본 정보
원래 장소: jiangsu.china
브랜드 이름: ShengFan
인증: ROSH SGS
모델 번호: QSP-1
결제 및 배송 조건
포장 세부 사항: 플라스틱 버블/ 폴리스티렌 폼 시트/ 상자/ 목재 팔레트
공급 능력: 한 달에 10000 조각/조각
제품 설명
Custom Quartz Glass Plate for Precision Optics

Available in various sizes and shapes to meet your specific requirements.

Shengfan Quartz Plate Characteristics
Brand shengfanquartz
SIO2 99.99%
Density 2.2(g/cm³)
Degree of hardness moh' scale 6.6
Melting point 1732℃
Working temperature 1100℃
Annealing point 1180℃
Softening point 1630℃
Specification Information
Color Transparent
Shape Mixed
Standard JGS1, JGS2, JGS3
Material 99.99% sio2
Diameter 1-800mm
Thickness 0.2-100mm
Application Optics quartz windows
Density 6.6
Light Transmittance >92%
Hardness Mose 6.5
Resistance Value 1000 times than ordinary glass
Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 0
Customization Process
  1. Provide drawings with dimensions (unit: mm)
  2. We manufacture products according to your drawings

Additional requirements such as tolerance, polish, translucency, etc. can be accommodated based on your specifications.

Application Scope

Our quartz glass plates are used in:

  • Semiconductor manufacturing
  • Electric light source devices
  • Semiconductor communication devices
  • Laser technology
  • Optical instruments
  • Laboratory equipment
  • Electrical and medical devices
  • Chemical, electronic, and metallurgical industries
Product Advantages
  • High corrosion resistance
  • Exceptional temperature tolerance
  • Aesthetically pleasing appearance
  • Compact and durable structure
  • Excellent light transmission
  • Superior electrical insulation
Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 1 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 2 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 3 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 4 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 5 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 6 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 7 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 8
Production Process
Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 9 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 10 Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 11
Applications
Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 12
Product Uses
Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 13
Packing & Delivery
Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 14
Company Introduction

Lianyungang Shengfan Quartz Product Factory is a professional manufacturer specializing in research and development of quartz plates, quartz tubes, quartz flanges, quartz rings, cuvettes, and quartz instruments. Located in China Crystal Capital - Donghai City, Jiangsu Province, China, just 70 km from Lianyungang port for convenient transportation.

Our facility covers 1000 square meters with over 30 employees, achieving annual sales exceeding USD 5.2 million. Guided by our philosophy of Technology Orientation, Quality First, Integrity and Responsibility, and Sustainable Operation, we are committed to building an international enterprise with standardized and sustainable operation capabilities.

Custom High Temperature Resistance (1150℃) Quartz Glass Plate with High Light Transmittance (>92%) and High Hardness (Morse 6.5) for Precision Optics 15
Our Services & Strength

We adhere to business integrity, offer competitive pricing with quality assurance, and provide excellent after-sales service. We welcome customers to discuss their requirements with us.

Frequently Asked Questions
Q1. Can I have a sample order?
A: Yes, we welcome sample orders to test and check quality.
Q2. What about the delivery time?
A: Within 15 days after receiving deposit.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. How to proceed an order in your factory?
  1. Share your requirements or application
  2. We provide quotation based on requirements
  3. Customer confirms samples and places deposit
  4. We arrange production
Q5. How do you ship the goods and how long does it take to arrive?
A: DHL, UPS, FedEx or TNT for small orders (3-5 days). Airline and sea shipping also available.
