| Type: | Clear Quartz Plate | Application: | Semiconductor, optical |
|---|---|---|---|
| Thickness: | 0.5-100mm | Shape: | Mixed |
| Processing Service: | Bending, Welding, Punching, polishing | Product Name: | quartz plate |
| Material: | SIO2>99.99% | Density: | 2.2g/cm3 |
| Working Temparature: | 1150℃ | Hardness: | Morse 6.5 |
| Melt Point: | 1750-1850℃ | Acid tolerance: | 30 times than Ceramics,150 times than stainless steel |
| Size: | Customized | Annealing point: | 1180℃ |
| Strain point: | 1100℃ | Port: | shanghai and Qindao port |
| 강조하다 |
고강도 석영 유리 플레이트,산업용 석영 유리 플레이트 |
||
|
Shengfan 석영판 특성
|
||
| *브랜드 | shengfanquartz | |
| *SIO2 | 99.99% | |
| *밀도 | 2.2(g/cm³) | |
| *경도 moh’ scale | 6.6 | |
| *융점 | 1732℃ | |
| * 작동 온도 | 1100℃ | |
| *어닐링점 | 1180℃ | |
| *연화점 | 1630℃ | |
| 설정 정보 | ||
| 색상 | 투명 | |
| 모양 | 혼합 | |
| 표준 | JGS1,JGS2,JGS3 | |
| 재료 | 99.99% sio2 | |
| 직경 | 1-800mm | |
| 두께 | 0.2-100mm | |
| 응용 분야 | 광학 석영 창 | |
| 밀도 | 6.6 | |
| 광선 투과율 | >92% | |
| 경도 | Mose 6.5 | |
| 저항 값 | 일반 유리보다 1000배 | |
맞춤 설정 방법?
Shengfan 석영판 특성 *브랜드 shengfanquartz *SIO2 99.99% *밀도 2.2(g/cm³) *경도 moh’ scale 6.6 *융점 1732℃ * 작동 온도 1100℃ *어닐링점 1180℃ *연화점 1630℃ 설정 정보 색상 투명 모양 혼합 표준 JGS1,JGS2,JGS3 재료 99.99% sio2 직경 1-800mm 두께 0.2-100mm 응용 분야 광학 석영 창 밀도 6.6 광선 투과율 >92% 경도 Mose 6.5 저항 값 일반 유리보다 1000배 맞춤 설정 방법? 1. 치수 도면 작성 2. 도면대로 제...
Thin Quartz Glass Plate Dimensional Stable 1-1000mm Processing Range Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Specification Quick Details Place of Origin Jiangsu,China Brand SF Material Glass,High quality Optical Glass Usage Optical Structure Double Convex Shape
Product description: 1.SiO2> 99.99% ,tubing fused quartz 2.Operating Temperature: 1250℃ 3.Excellent visual and chemical performance . 4.Without surface coating andinfectant . 5.Health care and environmental protection. 6.Any specification can be made. 7.Quartz glass is acidic materials, except hydro fluoric acid and 300 degrees Celsius thermal phosphoric acid, on any other acids were shown to be inert, is the best anti acid materials. The advantages of Customized High Quality
No Air Bubble Flat Glass Plates Excellent Visual Performance Circular Shape Quartz Glass Window Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Application of quartz plate: Military industrial complex, machinery, metallurgy, printing and dyeing, optical instruments, high
Product description: Fused clear silica quartz glass plate is made of high purity quartz sand with excellent thermal shock stability and high transmittance. It is widely used in electric light/ laser/ lenses/optical instrument/high temperature window. Application of quartz plate: Military industrial complex, machinery, metallurgy, printing and dyeing, optical instruments, high temperature sight glasses, fire hole industries such as high temperature and other industries,
아래의 온라인 문의 연락 양식을 사용하시기 바랍니다. 질문이 있으시면 저희 팀이 가능한 한 빨리 연락합니다.
